Name: 6 Nozzles Hand Wash Shampoo Filling Machines Cosmetic Food Paste Bottle Liquid Filling Machine Capping Labeling Line - Custom Making Machine Supplier - Guangzhou guanyu
Price: 10000.00 USD
Availability: InStock

6 Nozzles Hand Wash Shampoo Filling Machines Cosmetic Food Paste Bottle Liquid Filling Machine Capping Labeling Line

Product configuration

Max filling speed	filling 200ml, 2000~3000 pcs/hour, speed will be different when bottle shape and neck size and the filling material forming andother physical property
Applicable bottle diameter size	30-300（mm）
Applicable bottle height size	30-350（mm）
Filling dose	100~ 1000ml （Customizable）
Filling accuracy	±1%
Voltage	AC220V, single phase, 50/60HZ
Power	1.0KW
Working pressure	0.6MPa
Program control	PLC+touch screen man-machine interface
Capping speed	2000-3000 bottles/hour
Lower cover way	Manual or vibrating plate
Machine direction	from left to right

Main Features（Filling machine）：

1、The equipment has strong compatibility, and can quickly adjust and replace bottles of different shapes and specificationswithout replacing parts, which can meet the production requirements of multiple varieties and

specifications.

2、PLC control ,touch bottle operatation ,simple and convenient operation.

3、The use of internatioal famouse brand electrical components, performance and stability.4、User can adjust filling range, the materials is not enough in hopper, the computer will give the feeding pump signal to addmaterial by level sensor. When the material is full, the pump will stop automatically.

5、Machine body is made by 304 stainless steel, easy to clean, machine is full compliance with GMP requirements.

6、Peristaltic pump or piston pump filling system, measuring precision, convenient manipulation.

Main Features（Capping machine）：

1.No lids,no screwing,automatic detection.

2.Which can be match with packing line.3.Touch screen and button operation can be optional.4.which applied for different cap in different material and different specifications.5.Which adopt identity torsion capping head, the capping device could not hurt the cap .6.which use 3-roller type capping knife ,it is easy to regulate the pressure.7.which applied for metal cap ,screw type cap , pilfer-proofcap, compression cap, etc…
