Guanyu 1T/2T/3T Vacuum 3 Layers Emulsifier Homogenizer Mixer Cosmetic Face Cream Homogenizing Mixing Tank Essential Oil Reactor

Category
Guanyu 1T/2T/3T Vacuum 3 Layers Emulsifier Homogenizer Mixer Cosmetic Face Cream Homogenizing Mixing Tank Essential Oil Reactor
Products Description
Guanyu 1T/2T/3T Vacuum 3 Layers Emulsifier Homogenizer Mixer Cosmetic Face Cream Homogenizing Mixing Tank Essential Oil Reactor

Our Advantages:

◭ 25 Years: Guangzhou Guanyu Machinery Co.Ltd has been engaged in research and manufacture of machinery for medical, food and industrial chemicals for 25 years.
◭ Our own factory: Our factory has 7000 square meters, more than 100 workers, and 6 machine production lines, including machine manufacturing, polishing, and testing.
◭ Customized Machinery: Our main products include fixed vacuum emulsifying machines, mobile homogenizers, all kinds of reaction agitator kettles.
◭ Applicable Products: They are suitable for making cream, lotion, liquid products, including face cream, ointments, ketchup, mayonnaise, jam, hand soap, shampoo etc.
◭ Certifications: CE, GMP, UL and patented technology certificates.

All machines are customized for you!
Model
Volume(L)

Blending

Power(kw)

Blending

rotation speed
(r/m)
Homogenizing power(kw)
Homogenizing speed(r/min)
Heating method
GY-200
200
1.5
0~63
4.0
0~3200
steam heating or electirc heating
GY-500
500
3.0
0~63
7.5
0~3200
GY-1000
1000
4.0
0~63
11
0~3200
GY-1500
1500
5.5
0~63
11-15
0~3200
GY-2000
2000
7.5
0~63
15-15.8
0~3200
GY-3000
3000
7.5-11
0~63
18.5-22
0~3200
GY-5000
5000
11
0~63
18.5-22
0~3200
Guanyu 1T/2T/3T Vacuum 3 Layers Emulsifier Homogenizer Mixer Cosmetic Face Cream Homogenizing Mixing Tank Essential Oil Reactor

Stainless Steel Mixing Tank has mixing agitator,bottom homogenizer,stainless steel jacket tank shell,motor,electric control box,operation platform,staircase,etc.

◭The scraper type agitator mixing adopts the frequency converter for speed adjustment , so that high quality products of different processes according to customer requirements.

◭The diversified high-speed homogenizer can powerfully mix solid and liquid raw materials and can rapidly dissolve
many indissoluble materials such as AES , AESA , LSA , etc. during the liquid detergent production process so as to save energy consumpion and shorten production period. High Shear Homoegnizer adopts German Technology, 0~3500rpm variable speed, and maximumspeed can reach to 4500rpm,the shear degree is about 0.2~5um.

◭The tank body is welded by imported three-layer stainless steel plate. The tank body and the pipes adopt mirror polishing or matte finish , which fully conforms to GMP requirements.

◭According to customer requirement , the tank can heat and cool materials. The heating way including steam heating and electric heating. Easy to discharge , bottom direct discharge or by transfer pump.

◭We can choose PLC automatic control system ,or manual button control box,it depends upon your demand.

Mixing paddle

Variable frequency speed regulation is 0-62r/min, so that different materials can be mixed evenly. The shape of the mixing paddle will be designed according to your materials

Homogenizer

Frequency conversion speed regulation 0-3200r/min, homogeneous shearing head high-speed shearing materials, so that the materials are completely broken and mixed!

Vacuum Pumps

Under the vacuum environment, the emulsification pot can discharge foam when the materials are mixed, thus improving the quality of the materials to be treated. Vacuum deaeration process can ensure the sterility of materials

Discharge

The round bottom of the pot is designed to make the bottom discharge cleaner and reduce the residue of materials
(if necessary, a discharge pump can be equipped to directly extract materials)

Console

The control box includes settings such as homogeneous shearing, frequency conversion speed regulation mixing,
working timing, vacuum extraction, interlayer heating, etc.
(PLC control is optional)

Service

Use internationally renowned brand components to ensure the quality of the equipment and longer service life

In order to provide you with a more suitable machine, please contact us to discuss the details

1.What is your product?
2.What is your daily output?
3.Is heating required?
4.Is it necessary to vacuum?
5.Whether frequency conversion speed regulation is needed?
6.What is your local voltage?
