12 Nozzles Dishwashing Liquid Automatic Filling Machine Shampoo Hand Wash Liquid Soap cosmetic Bottle Filling Machine

Category
12 Nozzles Dishwashing Liquid Automatic Filling Machine Shampoo Hand Wash Liquid Soap cosmetic Bottle Filling Machine
Product configuration
Dishwashing Liquid Automatic Filling Machine
Dishwashing Liquid Automatic Filling Machine
Ha8ad87593e544857b01ff2ca876cd727t
Hf56107f437054d55a504969793a05804O
Max filling speed
filling 200ml, 2000~3000 pcs/hour, speed will be different when bottle shape and neck size and the filling material forming andother physical property
Applicable bottle diameter size
30-300(mm)
Applicable bottle height size
30-350(mm)
Filling dose
500~ 5100ml (Customizable)
Filling accuracy
±1%
Voltage
AC220V, 50/60HZ
Power
5.0KW
Working pressure
0.4 ~ 0.6MPa
Program control
PLC+touch screen man-machine interface
Capping speed
2000-3000 bottles/hour
Lower cover way
Manual or vibrating plate
Machine direction
from left to right
DescriptionThis automatic production is designed for filling paste or thicker liquid,like honey, hand sanitizer, laundry detergent,machine oil.It can automatically fill paste,feed bottle caps and cap bottles.Equipped with a labeling machine,it can be a complete production line for production process.Each machine of this production line can work separately.
Hb6c883c812724be78577d5aa44d5b0d5X

Main Features(Filling machine):

1、The equipment has strong compatibility, and can quickly adjust and replace bottles of different shapes and specificationswithout replacing parts, which can meet the production requirements of multiple varieties and specifications.

2、PLC control ,touch bottle operatation ,simple and convenient operation.

3、The use of internatioal famouse brand electrical components, performance and stability.4、User can adjust filling range, the materials is not enough in hopper, the computer will give the feeding pump signal toaddmaterial by level sensor. When the material is full, the pump will stop automatically.5、Machine body is made by 304 stainless steel, easy to clean, machine is full compliance with GMP requirements.6、Peristaltic pump or piston pump filling system, measuring precision, convenient manipulation.

Hf3c5e8edbedb4ccf9288cea5b7be1e5az

Main Features(Capping machine):

1.No lids,no screwing,automatic detection.

2.Which can be match with packing line.3.which applied for different cap in different material and different specifications.4.Which adopt identity torsion capping head, the capping device could not hurt the cap .5.which use 3-roller type capping knife ,it is easy to regulate the pressure.6.which applied for metal cap ,screw type cap , pilfer-proofcap, compression cap, etc…
